Laser welding machine

Product Inquiry

Product Brochure

Related Products

Product Images

Product Parameters

Product Advantages

Product Cutting Video

Product Images

Click to view large image

Product Parameters

model	Laser power	Laser wavelength	Operating voltage	Fiber length	Power adjustment range	Gun head weight	Overall dimensions	Weld requirements	Welding speed	Cooling method	Operating temperature range	Ambient temperature range
SHC-1500WDS	1500W	1080nm	Single-phase 220V 50HZ/60HZ	10-20 meters (customizable)	0-1500W	0.7kg	Main unit 14565105cm Wire feeder 562535cm	0-8mm	60-120cm/min	Water cooling	22-28 degrees Celsius	5-40 degrees Celsius
SCH-2000WDS	2000W	1080nm	Three-phase 220V 50HZ/60HZ	10-20 meters (customizable)	0-2000W	0.7kg	Main unit 14565105cm Wire feeder 562535cm	0-8mm	60-150cm/min	Water cooling	22-28 degrees Celsius	5-40 degrees Celsius
SCH-3000WDS	3000W	1080nm	Three-phase 380V 50HZ/60HZ	10-20 meters (customizable)	0-3000W	0.7kg	Main unit 16565135cm Wire feeder 562535cm	0-8mm	60-150cm/min	Water cooling	22-28 degrees Celsius	5-40 degrees Celsius

Product Advantages

Unique fiber laser handheld welding control system, capable of welding and cutting, and can be used with robots for higher efficiency.

Unique welding head with air blowing control and safety lock (no contact with metal, no light, to avoid injury).

The welding speed is fast and the operation is simple. You can start working after simple training. You don’t need an experienced technician to weld beautiful products.

Welding requires no consumables, only electricity is needed, saving consumable costs.

The weld is smooth and beautiful, reducing the subsequent grinding process, saving time and cost.

The welding effect is good, the welded parts have no deformation, no weld scars, and the welding is firm.

Low radiation, safer for operators, and reduces the risk of occupational diseases.

We independently developed a welding head to overcome the disadvantage of the small laser welding spot, expand the tolerance range of the processed parts and the weld width, and achieve better weld formation.
